| Unit | TRY 100M | TRY 110M | TRY 120M | TRY 160M | TRY 200M | |
|---|---|---|---|---|---|---|
| Production Capacity | m³/hour | 100 | 110 | 120 | 160 | 200 |
| MIXER | ||||||
| Mixer Type | - | Twin Shaft | Twin Shaft | Twin Shaft | Twin Shaft | Twin Shaft |
| Mixer Volume | liter | 3000/2000 | 3750/2500 | 4500/3000 | 6000/4000 | 7500/5000 |
| Mixer Capacity | m³ | 2,00 | 2,25 | 3,00 | 4,00 | 5,00 |
| Mixer Motor | KW | 2 x 37 | 2 x 45 | 2 x 55 | 2 x 75 | 2 x 90 |
| Lubrication System | - | Automatic | Automatic | Automatic | Automatic | Automatic |
| AGGREGATE BUNKER | Number of Bins | each | 2 - 8 | 2 - 8 | 2 - 8 | 2 - 8 | 2 - 8 |
| Bin Capacity | m³ | 30 | 30 | 30 - 40 | 30 - 50 | 30 - 50 |
| WEIGHING CAPACITY | ||||||
| Aggregate | kg | 6.000 | 6.000 | 8.000 | 8.000 | 10.000 |
| Water | lt | 600 | 750 | 900 | 1200 | 1500 |
| Cement | kg | 1200 | 1500 | 1800 | 2400 | 3000 |
| Additive | lt | 20 | 20 | 50 | 50 | 100 |
| Weighing System | - | Electronic - Digital | Electronic - Digital | Electronic - Digital | Electronic - Digital | Electronic - Digital |
| AGGREAGATE INTERMEDIATE BIN | - | - | - | - | - | - |
| TRANSFER CONVEYOR | ||||||
| Conveyor Type | - | Chevron | Chevron | Chevron | Chevron | Chevron |
| Conveyor Length | mt | 15 | 15 | 15 | 15 | 15 |
| Conveyor Width | mm | 1000 | 1000 | 1000 | 1200 | 1200 |
| Conveyor Covarage | - | Optional | Optional | Optional | Optional | Optional |
| CEMENT SILO | ||||||
| Number of Silo | each | 1-4 | 1-4 | 1-4 | 1-4 | 1-4 |
| Silo Capacity | ton | 50 - 200 | 50 - 200 | 50 - 200 | 50 - 200 | 50 - 200 |
| Silo Filter | each | 1 - 4 | 1 - 4 | 1 - 4 | 1 - 4 | 1 - 4 |
| Filter Capacity | m² | 24 | 24 | 24 | 24 | 24 |
| CEMENT SCREW CONVEYOR | ||||||
| Screw Conveyor Diameter | 273 | 273 | 273 | 323 | 323 | |
| Number of Screw Conveyor | 1 - 4 | 1 - 4 | 1 - 4 | 1 - 4 | 1 - 4 | |
| COMPRESSOR | KW | 7.5 | 7.5 | 7.5 | 11 | 11 |
| WATER CONNECTION | Ø | 2" | 2" | 3" | 3" | 3" |
| HUMMIDITY PROB | - | Optional | Optional | Optional | Optional | Optional |
| COVARAGE | ||||||
| Bunker | Optional | Optional | Optional | Optional | Optional | |
| Main Chassis | Optional | Optional | Optional | Optional | Optional | |
| Total Power | KW | Change depending on plant technical executions. | ||||
