| Unit | TRY 30M | TRY 60M | |
|---|---|---|---|
| Production Capacity | m³/hour | 30 | 60 |
| MIXER | |||
| Mixer Type | - | Single / Planet | Single / Planet |
| Mixer Volume | liter | 750/500 | 1500/1000 |
| Mixer Capacity | m³ | 0,50 | 1,00 |
| Mixer Motor | KW | 18.5 | 37-45 |
| Lubrication System | - | Automatic | Automatic |
| AGGREGATE BUNKER | Number of Bins | each | 2 - 4 | 2 - 4 |
| Bin Capacity | m³ | 12 | 12 |
| WEIGHING CAPACITY | |||
| Aggregate | kg | 2.000 | 4.000 |
| Water | lt | 150 | 300 |
| Cement | kg | 300 | 600 |
| Additive | lt | 20 | 20 |
| Weighing System | - | Electronic - Digital | Electronic - Digital |
| AGGREAGATE INTERMEDIATE BIN | - | - | - |
| TRANSFER CONVEYOR | |||
| Conveyor Type | - | Chevron | Chevron |
| Conveyor Length | mt | 14 | 14 |
| Conveyor Width | mm | 800 | 800 |
| Conveyor Covarage | - | Optional | Optional |
| CEMENT SILO | |||
| Number of Silo | each | 1-2 | 1-2 |
| Silo Capacity | ton | 30 - 200 | 30 - 200 |
| Silo Filter | each | 1 - 2 | 1 - 2 |
| Filter Capacity | m² | 24 | 24 |
| CEMENT SCREW CONVEYOR | |||
| Screw Conveyor Diameter | mm | 219 | 219 |
| Number of Screw Conveyor | each | Optional | Optional |
| COMPRESSOR | KW | 5.5 | 5.5 |
| WATER CONNECTION | Ø | 1" | 2" |
| HUMMIDITY PROB | - | Optional | Optional |
| COVARAGE | |||
| Bunker | Optional | Optional | |
| Main Chassis | Optional | Optional | |
| Total Power | KW | Change depending on plant technical executions. | |
